Vortex Flow Meter

Model / Series: AN-F-WJ003

Smart vortex flow meter for liquids, gases and steam with optional temperature-pressure compensation.

Bore: DN15–DN300
Other: Accuracy ±0.5%–±1.0%; optional T/P compensation; 4-20mA/pulse/HART/RS485; anti-vibration; stainless steel; Ex optional
Range: Gas 1.5–60 m/s; liquid 0.3–7 m/s; turndown 1:15
Medium: Liquids, gases, saturated/superheated steam
Installation: Flange integral, wafer, insertion; horizontal/vertical

Function

Based on the Karman vortex street principle, the smart vortex flow meter meters liquids, gases and steam in one device with strong versatility. A built-in HD LCD shows instantaneous flow, total and velocity, and an optional integrated temperature-pressure compensation module automatically converts to standard-condition flow for higher accuracy. 4-20mA and pulse outputs with HART and RS485 connect directly to layered automation systems.

Features & Advantages

No moving parts inside the pipe means wear resistance, no zero drift, long-term stability and very low maintenance cost. An anti-vibration sensing structure resists pipe vibration, with accuracy up to ±0.5%–±1.0% and a turndown up to 1:15. Full stainless steel construction resists corrosion and high temperature/pressure for complex conditions, with export certification meeting global tender standards.

Applications & Industries

Widely used in district heating, natural gas, compressed air, petrochemicals, power, metallurgy and light industry. A universal meter for steam, gas and industrial liquids in overseas plant packages.

Models & Options

Standard bores DN15–DN300 with flange, wafer and insertion mounting; high-temperature, high-pressure and explosion-proof options; ANSI, JIS and DIN flanges; parameter modification, OEM branding and batch turnkey export.
